65505(F116Q1) 65605(F116Q3)

Instructions Download>

Model

65505(F116Q1)

65605(F116Q3)

Installation

Top-mounted

Inlet/outlet

1"M

Drain

3/4" NPT

Brine line connector

3/8" M

Base

2.5"-8NPSM

Riser pipe

1.05"OD

Water treatment capacity

5 m³/h

Tank diameter range

6"~18"

Water pressure

0.15MPa0.6MPa

Water temperature

550

Water turbidity

Down flow regeneration5FTU

Power adapter

Input AC100240V/5060Hz

Output DC12V/1.5A


Product description
